3230-1-00-15-00-00-08-0
Mill-Max- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PC PIN CIRC .040DIA GOLD
- CategoryTerminals - PC Pin, Single Post Connectors
-
ECAD Model
- Share
In Stock: 195
Can ship immediately
Pricing:
- 1$0.52992
Quote It
Technical Details
- Series:3230
- Package:Bulk
- Part Status:Active
- Terminal Type:PC Pin
- Terminal Style:Single End
- Pin Size - Above Flange:0.040" (1.02mm) Dia
- Pin Size - Below Flange:-
- Length - Above Flange:0.202" (5.13mm)
- Length - Below Flange:0.065" (1.65mm)
- Length - Overall:0.307" (7.80mm)
- Flange Diameter:0.109" (2.77mm)
- Mounting Hole Diameter:0.094" (2.39mm)
- Mounting Type:Through Hole
- Termination:Swage
- Insulation:Non-Insulated
- Board Thickness:0.031" (0.79mm)
- Contact Material:Brass Alloy
- Contact Finish:Gold
- Contact Finish Thickness:10.0µin (0.25µm)
