3114-2-00-34-00-00-08-0
Mill-Max
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PC PIN CIRC .025DIA GOLD
- CategoryTerminals - PC Pin, Single Post Connectors
-
ECAD Model
- Share
In Stock: 175
Can ship immediately
Pricing:
- 1$0.53104
Quote It
Technical Details
- Series:3114
- Package:Bulk
- Part Status:Active
- Terminal Type:PC Pin
- Terminal Style:Single End
- Pin Size - Above Flange:0.025" (0.64mm) Dia
- Pin Size - Below Flange:-
- Length - Above Flange:0.150" (3.81mm)
- Length - Below Flange:0.082" (2.08mm)
- Length - Overall:0.252" (6.40mm)
- Flange Diameter:0.050" (1.27mm)
- Mounting Hole Diameter:0.035" (0.89mm)
- Mounting Type:Through Hole
- Termination:Swage
- Insulation:Non-Insulated
- Board Thickness:0.062" (1.57mm)
- Contact Material:Brass Alloy
- Contact Finish:Gold
- Contact Finish Thickness:50.0µin (1.27µm)
