ER9.5/2.5/5-3C97-A100-S
FERROXCUBE
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPLANAR ER CORES 2PC SET
- CategoryFerrite Cores
- Datasheet ER9.5/2.5/5-3C97-A100-S Datasheet
-
ECAD Model
- Share
In Stock: 128
Can ship immediately
Pricing:
- 1$0.56776
- 900$0.56776
Quote It
Technical Details
- Series:*
- Package:Bulk
- Part Status:Active
- Core Type:ER
- Supplier Device Package:ER 9.5 x 2.5 x 5
- Material:3C97
- Diameter:-
- Inductance Factor (Al):100 nH
- Tolerance:±5%
- Gap:Gapped
- Effective Permeability (µe):133
- Initial Permeability (µi):-
- Core Factor (ΣI/A) mm-1:1.67
- Effective Length (le) mm:14.2
- Effective Area (Ae) mm²:8.47
- Minimum Core Cross Section (Amin) mm²:7.6
- Effective Magnetic Volume (Ve) mm³:120
- Finish:Uncoated
- Height:-
- Length:9.50mm
- Width:5.00mm
