RUE400-1

Technical Details

• Series:PolySwitch®
• Package:Bulk
• Part Status:Obsolete
• Type:Polymeric
• Voltage - Max:30V
• Current - Max:40 A
• Current - Hold (Ih) (Max):4 A
• Current - Trip (It):8 A
• Time to Trip:12.7 s
• Resistance - Initial (Ri) (Min):10 mOhms

• Resistance - Post Trip (R1) (Max):50 mOhms
• Resistance - 25°C (Typ):-
• Operating Temperature:-40°C ~ 85°C
• Ratings:-
• Mounting Type:Through Hole
• Package / Case:Radial, Disc
• Size / Dimension:0.551" L x 0.120" W (14.00mm x 3.00mm)
• Height - Seated (Max):0.831" (21.10mm)
• Thickness (Max):-
• Lead Spacing:0.201" (5.10mm)
