YPBL0055N

Technical Details

• Series:YP
• Package:Bulk
• Part Status:Obsolete
• Type:Ceramic
• Voltage - Max:80V
• Current - Max:700 mA
• Current - Hold (Ih) (Max):50 mA
• Current - Trip (It):100 mA
• Time to Trip:-
• Resistance - Initial (Ri) (Min):-

• Resistance - Post Trip (R1) (Max):-
• Resistance - 25°C (Typ):55 Ohms
• Operating Temperature:0°C ~ 60°C
• Ratings:-
• Mounting Type:Through Hole
• Package / Case:Radial, Disc
• Size / Dimension:0.157" Dia x 0.138" T (4.00mm x 3.50mm)
• Height - Seated (Max):0.217" (5.50mm)
• Thickness (Max):-
• Lead Spacing:0.200" (5.08mm)
