8838-0-15-01-34-01-10-0
Mill-Max- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PIN RCPT
- CategoryTerminals - PC Pin Receptacles, Socket Connectors
- Datasheet 8838-0-15-01-34-01-10-0 Datasheet
-
ECAD Model
- Share
In Stock: 196
Can ship immediately
Pricing:
- 1$0.68128
- 1,000$0.67968
Quote It
Technical Details
- Series:8838
- Package:Bulk
- Part Status:Active
- Tail Type:No Tail
- Termination:Solder
- Length - Overall:0.296" (7.52mm)
- Accepts Pin Diameter:0.032" ~ 0.046" (0.81mm ~ 1.17mm)
- Accepts Square Pin Size:-
- Pin Hole Diameter:0.064" (1.63mm)
- Mounting Hole Diameter:0.086" (2.18mm)
- Flange Diameter:0.115" (2.92mm)
- Tail Diameter:-
- Socket Depth:0.250" (6.35mm)
- Contact Material:Beryllium Copper
- Contact Finish:-
- Contact Finish Thickness:30.0µin (0.76µm)
