1053-2-17-01-34-01-02-0
Mill-Max
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PIN RCPT .032-.046 PRESSFIT
- CategoryTerminals - PC Pin Receptacles, Socket Connectors
- Datasheet 1053-2-17-01-34-01-02-0 Datasheet
-
ECAD Model
- Share
In Stock: 118
Can ship immediately
Pricing:
- 1$0.7432
- 1,000$0.7408
Quote It
Technical Details
- Series:1053
- Package:Bulk
- Part Status:Active
- Tail Type:Wire Wrap
- Termination:Press-Fit
- Length - Overall:0.610" (15.50mm)
- Accepts Pin Diameter:0.032" ~ 0.046" (0.81mm ~ 1.17mm)
- Accepts Square Pin Size:-
- Pin Hole Diameter:0.064" (1.63mm)
- Mounting Hole Diameter:0.083" (2.11mm)
- Flange Diameter:0.090" (2.29mm)
- Tail Diameter:0.025" (0.64mm) Square
- Socket Depth:0.220" (5.59mm)
- Contact Material:Beryllium Copper
- Contact Finish:Tin-Lead
- Contact Finish Thickness:200.0µin (5.08µm)
