SCE048LD2VC3F
Mallory Sonalert Products
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionALARM W/VOLUME CNTRL; 48VDC; 2KH
- CategoryAlarms, Buzzers, and Sirens
-
ECAD Model
- Share
In Stock: 139
Can ship immediately
Pricing:
- 1$31.19
Quote It
Technical Details
- Series:SCE
- Package:Bulk
- Part Status:Active
- Driver Circuitry:Indicator, Internally Driven
- Input Type:DC
- Voltage - Rated:-
- Voltage Range:28 ~ 48V
- Frequency:2kHz
- Technology:Piezo
- Operating Mode:Pulse, Medium
- Duration:5 PPS
- Sound Pressure Level (SPL):85dB @ 28V, 61cm
- Current - Supply:40mA
- Port Location:Top
- Operating Temperature:-40°C ~ 85°C
- Approval Agency:cUL, UL
- Ratings:-
- Ingress Protection:-
- Mounting Type:Panel Mount
- Termination:Screw Terminal, Quick Connect Tab - 0.250" (6.35mm), Wire Leads
- Size / Dimension:1.687" Dia (42.85mm)
- Height - Seated (Max):1.946" (49.43mm)
