SC250PR

Technical Details

• Series:SC
• Package:Bulk
• Part Status:Active
• Driver Circuitry:Indicator, Internally Driven
• Input Type:AC, DC
• Voltage - Rated:-
• Voltage Range:60 ~ 250V
• Frequency:2.9kHz
• Technology:Piezo
• Operating Mode:Pulse, Fast
• Duration:2 ~ 10 PPS

• Sound Pressure Level (SPL):68dB @ 60V, 61cm
• Current - Supply:4 ~ 13mA
• Port Location:Top
• Operating Temperature:-30°C ~ 65°C
• Approval Agency:cUL, UL
• Ratings:-
• Ingress Protection:-
• Mounting Type:Panel Mount
• Termination:Screw Terminal, Quick Connect Tab - 0.250" (6.35mm)
• Size / Dimension:1.687" Dia (42.85mm)
• Height - Seated (Max):1.399" (35.54mm)
