HSG-70-12

Technical Details

• Series:HSG-70 (70W)
• Package:Box
• Part Status:Obsolete
• Type:Constant Current, Voltage
• Topology:AC DC Converter
• Number of Outputs:1
• Voltage - Input (Min):90VAC
• Voltage - Input (Max):305VAC
• Voltage - Output:12V
• Current - Output (Max):5A
• Power (Watts):60 W

• Voltage - Isolation:3.75 kV
• Dimming:PWM
• Features:OCP, OTP, OVP, SCP
• Ratings:IP65
• Operating Temperature:-40°C ~ 70°C
• Efficiency:88%
• Termination Style:Wire Leads
• Size / Dimension:3.94" L x 3.54" W x 1.53" H (100.0mm x 90.0mm x 38.8mm)
• Approval Agency:CCC, CE
• Standard Number:-
