EEH-AZE1V151B
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM POLY 150UF 20% 35V T/H
- CategoryAluminum - Polymer Capacitors
-
ECAD Model
- Share
In Stock: 125
Can ship immediately
Pricing:
- 1$1.86
Quote It
Technical Details
- Series:ZE
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Type:Hybrid
- Capacitance:150 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):27mOhm
- Lifetime @ Temp.:2000 Hrs @ 145°C
- Operating Temperature:-55°C ~ 145°C
- Ratings:AEC-Q200
- Applications:Automotive
- Ripple Current @ Low Frequency:105 mA @ 100 Hz
- Ripple Current @ High Frequency:700 mA @ 100 kHz
- Impedance:-
- Lead Spacing:0.138" (3.50mm)
- Size / Dimension:0.315" Dia (8.00mm)
- Height - Seated (Max):0.413" (10.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
