52307-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RING CIRC 20AWG #2 CRIMP
- CategoryTerminals - Ring Connectors
- Datasheet 52307-1 Datasheet
-
ECAD Model
- Share
In Stock: 180
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:PIDG
- Package:Bulk
- Part Status:Active
- Terminal Type:Circular
- Stud/Tab Size:2 Stud
- Thickness:0.031" (0.79mm)
- Width - Outer Edges:0.182" (4.62mm)
- Length - Overall:0.731" (18.57mm)
- Mounting Type:Free Hanging (In-Line)
- Termination:Crimp
- Wire Gauge:20 AWG
- Insulation:Insulated
- Features:Insulation Restriction, Serrated Termination
- Color:Red, Red Stripe
- Contact Material:Copper
- Contact Finish:Tin
