7-36153-1
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RING CIRC 22AWG #10 CRIMP
- CategoryTerminals - Ring Connectors
- Datasheet 7-36153-1 Datasheet
-
ECAD Model
- Share
In Stock: 195
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:PIDG
- Package:Bulk
- Part Status:Active
- Terminal Type:Circular
- Stud/Tab Size:10 Stud
- Thickness:0.031" (0.79mm)
- Width - Outer Edges:0.312" (7.92mm)
- Length - Overall:0.909" (23.10mm)
- Mounting Type:Free Hanging (In-Line)
- Termination:Crimp
- Wire Gauge:22 AWG
- Insulation:Insulated
- Features:Insulation Restriction
- Color:Red, Green Stripe
- Contact Material:Copper
- Contact Finish:Tin
