HEF40174BP,652
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionD FLIP-FLOP
- CategoryLogic - Flip Flops
- Datasheet HEF40174BP,652 Datasheet
-
ECAD Model
- Share
In Stock: 4,725
Can ship immediately
Pricing:
- 1$0.51
Quote It
Technical Details
- Series:4000B
- Package:Tube
- Part Status:Obsolete
- Function:Master Reset
- Type:D-Type
- Output Type:Non-Inverted
- Number of Elements:1
- Number of Bits per Element:6
- Clock Frequency:45 MHz
- Max Propagation Delay @ V, Max CL:45ns @ 15V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:3mA, 3mA
- Voltage - Supply:3V ~ 15V
- Current - Quiescent (Iq):80 µA
- Input Capacitance:7.5 pF
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Through Hole
- Supplier Device Package:16-DIP
- Package / Case:16-DIP (0.300", 7.62mm)
