SN74LS73AN
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC FF JK TYPE DUAL 1BIT 14DIP
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 14,980
Can ship immediately
Pricing:
- 1$2.14
- 10$1.9207
- 25$1.81158
- 100$1.54345
- 500$1.26811
- 1,000$1.05072
- 2,500$0.97826
- 5,000$0.94202
Quote It
Technical Details
- Series:74LS
- Package:Tube
- Part Status:Active
- Function:Master Reset
- Type:JK Type
- Output Type:Complimentary
- Number of Elements:2
- Number of Bits per Element:1
- Clock Frequency:45 MHz
- Max Propagation Delay @ V, Max CL:20ns @ 5V, 45pF
- Trigger Type:Negative Edge
- Current - Output High, Low:400µA, 8mA
- Voltage - Supply:4.75V ~ 5.25V
- Current - Quiescent (Iq):6 mA
- Input Capacitance:-
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Through Hole
- Supplier Device Package:14-PDIP
- Package / Case:14-DIP (0.300", 7.62mm)
