74LCX74M
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionD FLIP-FLOP, LVC/LCX/Z SERIES, 2
- CategoryLogic - Flip Flops
- Datasheet 74LCX74M Datasheet
-
ECAD Model
- Share
In Stock: 131,345
Can ship immediately
Pricing:
- 1$0.23
- 10$0.1955
- 100$0.14594
- 500$0.11467
- 1,000$0.08861
Quote It
Technical Details
- Series:74LCX
- Package:Bulk
- Part Status:Active
- Function:Set(Preset) and Reset
- Type:D-Type
- Output Type:Complimentary
- Number of Elements:2
- Number of Bits per Element:1
- Clock Frequency:150 MHz
- Max Propagation Delay @ V, Max CL:7ns @ 3.3V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:24mA, 24mA
- Voltage - Supply:2V ~ 3.6V
- Current - Quiescent (Iq):10 µA
- Input Capacitance:7 pF
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
