SN74ACT74NSR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSN74ACT74 DUAL POSITIVE-EDGE-TRI
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 9,188
Can ship immediately
Pricing:
- 1$0.24
- 2,000$0.19375
- 6,000$0.18125
- 10,000$0.16875
Quote It
Technical Details
- Series:74ACT
- Package:Bulk
- Part Status:Active
- Function:Set(Preset) and Reset
- Type:D-Type
- Output Type:Complimentary
- Number of Elements:2
- Number of Bits per Element:1
- Clock Frequency:210 MHz
- Max Propagation Delay @ V, Max CL:11ns @ 5V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:24mA, 24mA
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Iq):2 µA
- Input Capacitance:3 pF
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOP
- Package / Case:14-SOIC (0.209", 5.30mm Width)
