SN74HCT74DT
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC FF D-TYPE DUAL 1BIT 14SOIC
- CategoryLogic - Flip Flops
-
ECAD Model
- Share
In Stock: 1,086
Can ship immediately
Pricing:
- 1$0.86
- 1,250$0.3456
Quote It
Technical Details
- Series:74HCT
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Function:Set(Preset) and Reset
- Type:D-Type
- Output Type:Complimentary
- Number of Elements:2
- Number of Bits per Element:1
- Clock Frequency:46 MHz
- Max Propagation Delay @ V, Max CL:25ns @ 5.5V, 50pF
- Trigger Type:Positive Edge
- Current - Output High, Low:4mA, 4mA
- Voltage - Supply:4.5V ~ 5.5V
- Current - Quiescent (Iq):4 µA
- Input Capacitance:3 pF
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
