SN74BCT574DBR

Technical Details

• Series:74BCT
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Function:Standard
• Type:D-Type
• Output Type:Tri-State, Non-Inverted
• Number of Elements:1
• Number of Bits per Element:8
• Clock Frequency:77 MHz
• Max Propagation Delay @ V, Max CL:8.6ns @ 5V, 50pF

• Trigger Type:Positive Edge
• Current - Output High, Low:15mA, 64mA
• Voltage - Supply:4.5V ~ 5.5V
• Current - Quiescent (Iq):8 mA
• Input Capacitance:5.5 pF
• Operating Temperature:0°C ~ 70°C (TA)
• Mounting Type:Surface Mount
• Supplier Device Package:20-SSOP
• Package / Case:20-SSOP (0.209", 5.30mm Width)
