MOCD217R1VM
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOISO 2.5KV 2CH TRANS 8SOIC
- CategoryOptoisolators - Transistor, Photovoltaic Output
- Datasheet MOCD217R1VM Datasheet
-
ECAD Model
- Share
In Stock: 168
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Number of Channels:2
- Voltage - Isolation:2500Vrms
- Current Transfer Ratio (Min):100% @ 1mA
- Current Transfer Ratio (Max):-
- Turn On / Turn Off Time (Typ):7.5µs, 5.7µs
- Rise / Fall Time (Typ):3.2µs, 4.7µs
- Input Type:DC
- Output Type:Transistor
- Voltage - Output (Max):30V
- Current - Output / Channel:150mA
- Voltage - Forward (Vf) (Typ):1.05V
- Current - DC Forward (If) (Max):60 mA
- Vce Saturation (Max):400mV
- Operating Temperature:-40°C ~ 100°C
- Mounting Type:Surface Mount
- Package / Case:8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:8-SOIC
