- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOISO 3.75KV DARLINGTON 4SOP
- CategoryOptoisolators - Transistor, Photovoltaic Output
- Datasheet SFH692AT Datasheet
-
ECAD Model
- Share
In Stock: 193
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Number of Channels:1
- Voltage - Isolation:3750Vrms
- Current Transfer Ratio (Min):1000% @ 1mA
- Current Transfer Ratio (Max):-
- Turn On / Turn Off Time (Typ):1.5µs, 53.5µs
- Rise / Fall Time (Typ):1µs, 20.5µs
- Input Type:DC
- Output Type:Darlington
- Voltage - Output (Max):300V
- Current - Output / Channel:50mA
- Voltage - Forward (Vf) (Typ):1.2V
- Current - DC Forward (If) (Max):50 mA
- Vce Saturation (Max):1V
- Operating Temperature:-55°C ~ 100°C
- Mounting Type:Surface Mount
- Package / Case:4-SMD, Gull Wing
- Supplier Device Package:4-SOP (2.54mm)
