MAX319CPA
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMAX319 PRECISION ANALOG SWITCH
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet MAX319CPA Datasheet
-
ECAD Model
- Share
In Stock: 3,918
Can ship immediately
Pricing:
- 1$2.37
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:SPDT
- Multiplexer/Demultiplexer Circuit:2:1
- Number of Circuits:1
- On-State Resistance (Max):35Ohm
- Channel-to-Channel Matching (ΔRon):2Ohm (Max)
- Voltage - Supply, Single (V+):10V ~ 30V
- Voltage - Supply, Dual (V±):±4.5V ~ 20V
- Switch Time (Ton, Toff) (Max):175ns, 145ns
- -3db Bandwidth:-
- Charge Injection:3pC
- Channel Capacitance (CS(off), CD(off)):8pF, 8pF
- Current - Leakage (IS(off)) (Max):250pA
- Crosstalk:-85dB @ 1MHz
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Through Hole
- Package / Case:8-DIP (0.300", 7.62mm)
- Supplier Device Package:8-PDIP
