ISL84780IVZ-T
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSPDT ANALOG SWITCH, 4 FUNC, 1 CH
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet ISL84780IVZ-T Datasheet
-
ECAD Model
- Share
In Stock: 3,507
Can ship immediately
Pricing:
- 1$3.3
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Switch Circuit:SPDT
- Multiplexer/Demultiplexer Circuit:2:1
- Number of Circuits:4
- On-State Resistance (Max):600mOhm
- Channel-to-Channel Matching (ΔRon):130mOhm
- Voltage - Supply, Single (V+):1.65V ~ 3.6V
- Voltage - Supply, Dual (V±):-
- Switch Time (Ton, Toff) (Max):20ns, 14ns
- -3db Bandwidth:-
- Charge Injection:-97pC
- Channel Capacitance (CS(off), CD(off)):62pF
- Current - Leakage (IS(off)) (Max):3nA
- Crosstalk:-98dB @ 100kHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:16-TSSOP
