SN74LV4052AN
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSN74LV4052A DUAL 4-CHANNEL ANALO
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
-
ECAD Model
- Share
In Stock: 84,321
Can ship immediately
Pricing:
- 1$0.24
- 10$0.20656
- 25$0.19279
- 100$0.15423
- 500$0.12118
- 1,000$0.09364
- 2,500$0.08538
- 5,000$0.07987
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Switch Circuit:SP4T
- Multiplexer/Demultiplexer Circuit:4:1
- Number of Circuits:2
- On-State Resistance (Max):75Ohm
- Channel-to-Channel Matching (ΔRon):700mOhm
- Voltage - Supply, Single (V+):2V ~ 5.5V
- Voltage - Supply, Dual (V±):-
- Switch Time (Ton, Toff) (Max):14ns, 14ns
- -3db Bandwidth:50MHz
- Charge Injection:-
- Channel Capacitance (CS(off), CD(off)):0.5pF, 13.1pF
- Current - Leakage (IS(off)) (Max):100nA
- Crosstalk:-45dB @ 1MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Through Hole
- Package / Case:16-DIP (0.300", 7.62mm)
- Supplier Device Package:16-PDIP
