NLVHC4053ADTR2G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSPDT, 3 FUNC, 1 CHANNEL, CMOS, P
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet NLVHC4053ADTR2G Datasheet
-
ECAD Model
- Share
In Stock: 1,510
Can ship immediately
Pricing:
- 1$0.39
- 2,500$0.385
Quote It
Technical Details
- Series:Automotive, AEC-Q100
- Package:Bulk
- Part Status:Active
- Switch Circuit:SPDT
- Multiplexer/Demultiplexer Circuit:2:1
- Number of Circuits:3
- On-State Resistance (Max):100Ohm
- Channel-to-Channel Matching (ΔRon):10Ohm
- Voltage - Supply, Single (V+):2V ~ 6V
- Voltage - Supply, Dual (V±):±2V ~ 6V
- Switch Time (Ton, Toff) (Max):-
- -3db Bandwidth:80MHz
- Charge Injection:-
- Channel Capacitance (CS(off), CD(off)):130pF
- Current - Leakage (IS(off)) (Max):200nA
- Crosstalk:-
- Operating Temperature:-55°C ~ 125°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:16-TSSOP
