AD7506KNZ
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC MULTIPLEXER 16X1 28DIP
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet AD7506KNZ Datasheet
-
ECAD Model
- Share
In Stock: 175
Can ship immediately
Pricing:
- 1$47.09
- 13$43.92981
- 104$38.14286
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Switch Circuit:-
- Multiplexer/Demultiplexer Circuit:16:1
- Number of Circuits:1
- On-State Resistance (Max):450Ohm
- Channel-to-Channel Matching (ΔRon):18Ohm
- Voltage - Supply, Single (V+):-
- Voltage - Supply, Dual (V±):±15V
- Switch Time (Ton, Toff) (Max):1.5µs, 1µs
- -3db Bandwidth:-
- Charge Injection:-
- Channel Capacitance (CS(off), CD(off)):5pF, 40pF
- Current - Leakage (IS(off)) (Max):5nA
- Crosstalk:-
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Through Hole
- Package / Case:28-DIP (0.600", 15.24mm)
- Supplier Device Package:28-PDIP
