TS12A4517D
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH SPST 8SOIC
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
-
ECAD Model
- Share
In Stock: 1,102
Can ship immediately
Pricing:
- 1$0.92
- 975$0.5016
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Switch Circuit:SPST - NC
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:1
- On-State Resistance (Max):20Ohm
- Channel-to-Channel Matching (ΔRon):-
- Voltage - Supply, Single (V+):-
- Voltage - Supply, Dual (V±):±1V ~ 6V
- Switch Time (Ton, Toff) (Max):75ns, 45ns
- -3db Bandwidth:464MHz
- Charge Injection:-13pC
- Channel Capacitance (CS(off), CD(off)):5.5pF, 5.5pF
- Current - Leakage (IS(off)) (Max):5nA
- Crosstalk:-
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:8-SOIC
