ADG706BRU-REEL7
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSPST, 16 CHANNEL, CMOS
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet ADG706BRU-REEL7 Datasheet
-
ECAD Model
- Share
In Stock: 119
Can ship immediately
Pricing:
- 1$4.21
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Switch Circuit:-
- Multiplexer/Demultiplexer Circuit:16:1
- Number of Circuits:1
- On-State Resistance (Max):4.5Ohm
- Channel-to-Channel Matching (ΔRon):-
- Voltage - Supply, Single (V+):1.8V ~ 5.5V
- Voltage - Supply, Dual (V±):±2.5V
- Switch Time (Ton, Toff) (Max):32ns, 16ns (Typ)
- -3db Bandwidth:25MHz
- Charge Injection:8pC
- Channel Capacitance (CS(off), CD(off)):13pF, 180pF
- Current - Leakage (IS(off)) (Max):100pA
- Crosstalk:-80dB @ 1MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:28-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:28-TSSOP
