IH5049CPE
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIH5049 CMOS ANALOG SWITCH
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet IH5049CPE Datasheet
-
ECAD Model
- Share
In Stock: 123
Can ship immediately
Pricing:
- 1$7.86
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:SPST - NO
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:2
- On-State Resistance (Max):75Ohm
- Channel-to-Channel Matching (ΔRon):8Ohm
- Voltage - Supply, Single (V+):-
- Voltage - Supply, Dual (V±):±4.5V ~ 20V
- Switch Time (Ton, Toff) (Max):600ns, 300ns (Typ)
- -3db Bandwidth:-
- Charge Injection:10pC
- Channel Capacitance (CS(off), CD(off)):-
- Current - Leakage (IS(off)) (Max):100nA
- Crosstalk:-
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Through Hole
- Package / Case:16-DIP (0.300", 7.62mm)
- Supplier Device Package:16-PDIP
