ADG786WBCPZ-REEL7
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH TRIPLE SPDT 20LFCSP
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet ADG786WBCPZ-REEL7 Datasheet
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
- 1$2.09244
- 1,500$2.09244
Quote It
Technical Details
- Series:Automotive, ADI0012
- Package:Tape & Reel (TR)
- Part Status:Active
- Switch Circuit:SPDT
- Multiplexer/Demultiplexer Circuit:2:1
- Number of Circuits:3
- On-State Resistance (Max):4.5Ohm
- Channel-to-Channel Matching (ΔRon):-
- Voltage - Supply, Single (V+):1.8V ~ 5.5V
- Voltage - Supply, Dual (V±):±2.5V
- Switch Time (Ton, Toff) (Max):21ns, 10.5ns
- -3db Bandwidth:160MHz
- Charge Injection:5pC
- Channel Capacitance (CS(off), CD(off)):11pF
- Current - Leakage (IS(off)) (Max):100pA
- Crosstalk:-80dB @ 1MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:20-WFQFN Exposed Pad, CSP
- Supplier Device Package:20-LFCSP-WQ (4x4)
