MAX4053CSE+T
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC MULTIPLEXER TRPL 2X1 16SOIC
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet MAX4053CSE+T Datasheet
-
ECAD Model
- Share
In Stock: 136
Can ship immediately
Pricing:
- 1$2.483
- 2,500$2.19074
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Switch Circuit:SPDT
- Multiplexer/Demultiplexer Circuit:2:1
- Number of Circuits:3
- On-State Resistance (Max):100Ohm
- Channel-to-Channel Matching (ΔRon):12Ohm (Max)
- Voltage - Supply, Single (V+):2V ~ 16V
- Voltage - Supply, Dual (V±):±2.7V ~ 8V
- Switch Time (Ton, Toff) (Max):175ns, 150ns
- -3db Bandwidth:-
- Charge Injection:2pC
- Channel Capacitance (CS(off), CD(off)):2pF, 2pF
- Current - Leakage (IS(off)) (Max):1nA
- Crosstalk:-90dB @ 100kHz
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:16-SO
