MAX4536ESE+T
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH QUAD SPST 16SOIC
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet MAX4536ESE+T Datasheet
-
ECAD Model
- Share
In Stock: 180
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Switch Circuit:SPST - NO
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):100Ohm
- Channel-to-Channel Matching (ΔRon):1Ohm
- Voltage - Supply, Single (V+):2V ~ 12V
- Voltage - Supply, Dual (V±):±2V ~ 6V
- Switch Time (Ton, Toff) (Max):100ns, 50ns
- -3db Bandwidth:-
- Charge Injection:1pC
- Channel Capacitance (CS(off), CD(off)):2pF, 2pF
- Current - Leakage (IS(off)) (Max):2nA
- Crosstalk:-75dB @ 1MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:16-SO
