MAX4534CSD+T
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC MULTIPLEXER 4X1 14SOIC
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet MAX4534CSD+T Datasheet
-
ECAD Model
- Share
In Stock: 200
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Switch Circuit:SP4T
- Multiplexer/Demultiplexer Circuit:4:1
- Number of Circuits:1
- On-State Resistance (Max):400Ohm
- Channel-to-Channel Matching (ΔRon):2Ohm
- Voltage - Supply, Single (V+):9V ~ 36V
- Voltage - Supply, Dual (V±):±4.5V ~ 20V
- Switch Time (Ton, Toff) (Max):275ns, 200ns
- -3db Bandwidth:-
- Charge Injection:1pC
- Channel Capacitance (CS(off), CD(off)):5pF, 6.5pF
- Current - Leakage (IS(off)) (Max):500pA
- Crosstalk:-53dB @ 1MHz
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Surface Mount
- Package / Case:14-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:14-SOIC
