MAX4784EUE+T
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC MULTIPLEXER QUAD 2X1 16TSSOP
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet MAX4784EUE+T Datasheet
-
ECAD Model
- Share
In Stock: 166
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Switch Circuit:SPDT
- Multiplexer/Demultiplexer Circuit:2:1
- Number of Circuits:4
- On-State Resistance (Max):1Ohm
- Channel-to-Channel Matching (ΔRon):100mOhm
- Voltage - Supply, Single (V+):1.6V ~ 4.2V
- Voltage - Supply, Dual (V±):-
- Switch Time (Ton, Toff) (Max):25ns, 10ns
- -3db Bandwidth:123MHz
- Charge Injection:5pC
- Channel Capacitance (CS(off), CD(off)):33pF, 60pF
- Current - Leakage (IS(off)) (Max):1nA
- Crosstalk:-95dB @ 1MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:16-TSSOP
