DG200ABA
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH SPST DUAL TO100-10
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet DG200ABA Datasheet
-
ECAD Model
- Share
In Stock: 167
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Bag
- Part Status:Obsolete
- Switch Circuit:SPST - NC
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:2
- On-State Resistance (Max):80Ohm
- Channel-to-Channel Matching (ΔRon):-
- Voltage - Supply, Single (V+):-
- Voltage - Supply, Dual (V±):±4.5V ~ 18V
- Switch Time (Ton, Toff) (Max):1µs, 500ns
- -3db Bandwidth:-
- Charge Injection:10pC
- Channel Capacitance (CS(off), CD(off)):9pF, 9pF
- Current - Leakage (IS(off)) (Max):2nA
- Crosstalk:-90dB @ 1MHz
- Operating Temperature:-25°C ~ 85°C
- Mounting Type:Through Hole
- Package / Case:TO-100-10 Metal Can
- Supplier Device Package:TO-100-10
