DG401C/D

Technical Details

• Series:-
• Package:Tray
• Part Status:Active
• Switch Circuit:SPST - NO
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:2
• On-State Resistance (Max):45Ohm
• Channel-to-Channel Matching (ΔRon):500mOhm
• Voltage - Supply, Single (V+):10V ~ 30V, ±4.5V ~ 20V
• Voltage - Supply, Dual (V±):10V ~ 30V, ±4.5V ~ 20V

• Switch Time (Ton, Toff) (Max):150ns, 100ns
• -3db Bandwidth:-
• Charge Injection:10pC
• Channel Capacitance (CS(off), CD(off)):12pF, 12pF
• Current - Leakage (IS(off)) (Max):500pA
• Crosstalk:-90dB @ 1MHz
• Operating Temperature:0°C ~ 70°C (TA)
• Mounting Type:Surface Mount
• Package / Case:Die
• Supplier Device Package:Die
