MAX509AEPP+
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDAC, 4 FUNC, SERIAL INPUT LOADIN
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet MAX509AEPP+ Datasheet
-
ECAD Model
- Share
In Stock: 970
Can ship immediately
Pricing:
- 1$17.71
- 36$15.63556
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Number of Bits:8
- Number of D/A Converters:4
- Settling Time:6µs (Typ)
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:Microwire, QSPI, SPI
- Reference Type:External
- Voltage - Supply, Analog:4.5V ~ 5.5V
- Voltage - Supply, Digital:4.5V ~ 5.5V
- INL/DNL (LSB):±1
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:20-DIP (0.300", 7.62mm)
- Supplier Device Package:20-PDIP
- Mounting Type:Through Hole
