- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC DAC 10BIT A-OUT 16DIP
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet AD561JNZ Datasheet
-
ECAD Model
- Share
In Stock: 117
Can ship immediately
Pricing:
- 1$52.56
- 25$46.981
- 100$42.57639
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Bits:10
- Number of D/A Converters:1
- Settling Time:250ns (Typ)
- Output Type:Current - Unbuffered
- Differential Output:No
- Data Interface:Parallel
- Reference Type:Internal
- Voltage - Supply, Analog:4.5V ~ 16.5V, -10.8V ~ 16.5V
- Voltage - Supply, Digital:4.5V ~ 16.5V
- INL/DNL (LSB):±0.25, ±0.5
- Architecture:R-2R
- Operating Temperature:0°C ~ 70°C
- Package / Case:16-DIP (0.300", 7.62mm)
- Supplier Device Package:16-PDIP
- Mounting Type:Through Hole
