DAC8420FS-REEL
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionQUAD 12-BIT SERIAL V-OUT DAC
- CategoryData Acquisition - Digital to Analog Converters (DAC)
- Datasheet DAC8420FS-REEL Datasheet
-
ECAD Model
- Share
In Stock: 104
Can ship immediately
Pricing:
- 1$40.62
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Number of Bits:12
- Number of D/A Converters:4
- Settling Time:13µs (Typ)
- Output Type:Voltage - Buffered
- Differential Output:No
- Data Interface:SPI
- Reference Type:External
- Voltage - Supply, Analog:5V ~ 15V, -15V
- Voltage - Supply, Digital:5V
- INL/DNL (LSB):±1, ±0.25
- Architecture:R-2R
- Operating Temperature:-40°C ~ 85°C
- Package / Case:16-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:16-SOIC
- Mounting Type:Surface Mount
