3-84533-6
TE Connectivity AMP Connectors- Lifecycle status Active
- RoHS RoHS Compliant
- Description1.25MM FFC POST PLATED H 36P
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet 3-84533-6 Datasheet
-
ECAD Model
- Share
In Stock: 148
Can ship immediately
Pricing:
- 1$0.67564
- 19,200$0.65263
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Flat Flex Type:FFC
- Mounting Type:Through Hole, Right Angle
- Connector/Contact Type:Contacts, Top
- Number of Positions:36
- Pitch:0.049" (1.25mm)
- Termination:Kinked Pin
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.189" (4.80mm)
- Locking Feature:-
- Cable End Type:Tapered
- Contact Material:Phosphor Bronze
- Contact Finish:Tin
- Housing Material:Polybutylene Terephthalate (PBT), Glass Filled
- Actuator Material:-
- Features:-
- Voltage Rating:50V
- Operating Temperature:-40°C ~ 85°C
- Material Flammability Rating:-
