XF2M45151L
Omron Electronics Components
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FPC 45POS 0.50MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet XF2M45151L Datasheet
-
ECAD Model
- Share
In Stock: 145
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:XF2M
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Flat Flex Type:FPC
- Mounting Type:Surface Mount, Right Angle
- Connector/Contact Type:Contacts, Top and Bottom
- Number of Positions:45
- Pitch:0.020" (0.50mm)
- Termination:Solder
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.083" (2.10mm)
- Locking Feature:Rotary Lock, Backlock
- Cable End Type:Tapered
- Contact Material:Copper Alloy
- Contact Finish:Solder Plating
- Housing Material:Liquid Crystal Polymer (LCP)
- Actuator Material:Liquid Crystal Polymer (LCP)
- Features:-
- Voltage Rating:50V
- Operating Temperature:-30°C ~ 85°C
- Material Flammability Rating:UL94 V-0
