XF2L-1825-1A
Omron Electronics Components
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FPC TOP 18POS 0.50MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet XF2L-1825-1A Datasheet
-
ECAD Model
- Share
In Stock: 155
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:XF2L
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Flat Flex Type:FPC
- Mounting Type:Surface Mount, Right Angle
- Connector/Contact Type:Contacts, Top
- Number of Positions:18
- Pitch:0.020" (0.50mm)
- Termination:Solder
- FFC, FCB Thickness:0.30mm
- Height Above Board:0.047" (1.20mm)
- Locking Feature:Slide Lock
- Cable End Type:Straight
- Contact Material:Copper Alloy
- Contact Finish:Gold
- Housing Material:Liquid Crystal Polymer (LCP), Halogen Free
- Actuator Material:Liquid Crystal Polymer (LCP), Halogen Free
- Features:Zero Insertion Force (ZIF)
- Voltage Rating:50V
- Operating Temperature:-30°C ~ 85°C
- Material Flammability Rating:UL94 V-0
