FF0829SA1-R300
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN FPC BOTTOM 29POS 0.20MM R/A
- CategoryFFC, FPC (Flat Flexible) Connectors
- Datasheet FF0829SA1-R300 Datasheet
-
ECAD Model
- Share
In Stock: 200
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:FF08
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Flat Flex Type:FPC
- Mounting Type:Surface Mount, Right Angle
- Connector/Contact Type:Contacts, Bottom
- Number of Positions:29
- Pitch:0.008" (0.20mm)
- Termination:Solder
- FFC, FCB Thickness:0.15mm
- Height Above Board:0.039" (1.00mm)
- Locking Feature:Flip Lock
- Cable End Type:Tabbed
- Contact Material:Copper Alloy
- Contact Finish:Gold
- Housing Material:Plastic
- Actuator Material:Plastic
- Features:Zero Insertion Force (ZIF)
- Voltage Rating:50V
- Operating Temperature:-40°C ~ 85°C
- Material Flammability Rating:UL94 V-0
