MC74HC1G00DFT1GH
Rochester Electronics- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 1CH 2-INP SOEIAJ-14
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 12,119
Can ship immediately
Pricing:
- 1$0.12
Quote It
Technical Details
- Series:74HC
- Package:Bulk
- Part Status:Active
- Logic Type:NAND Gate
- Number of Circuits:1
- Number of Inputs:2
- Features:-
- Voltage - Supply:2V ~ 6V
- Current - Quiescent (Max):1 µA
- Current - Output High, Low:2.6mA, 2.6mA
- Logic Level - Low:0.5V ~ 1.8V
- Logic Level - High:1.5V ~ 4.2V
- Max Propagation Delay @ V, Max CL:17ns @ 6V, 50pF
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:SOEIAJ-14
- Package / Case:14-SOIC (0.209", 5.30mm Width)
