MM74HC86N

Technical Details

• Series:74HC
• Package:Tube
• Part Status:Obsolete
• Logic Type:XOR (Exclusive OR)
• Number of Circuits:4
• Number of Inputs:2
• Features:-
• Voltage - Supply:2V ~ 6V
• Current - Quiescent (Max):2 µA

• Current - Output High, Low:5.2mA, 5.2mA
• Logic Level - Low:0.5V ~ 1.8V
• Logic Level - High:1.5V ~ 4.2V
• Max Propagation Delay @ V, Max CL:20ns @ 6V, 50pF
• Operating Temperature:-40°C ~ 85°C
• Mounting Type:Through Hole
• Supplier Device Package:14-PDIP
• Package / Case:14-DIP (0.300", 7.62mm)
