SN74LV02ADR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NOR 4CH 2-INP 14SOIC
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 46,319
Can ship immediately
Pricing:
- 1$0.07
- 2,500$0.07
- 5,000$0.06517
- 12,500$0.06276
Quote It
Technical Details
- Series:74LV
- Package:Bulk
- Part Status:Active
- Logic Type:NOR Gate
- Number of Circuits:4
- Number of Inputs:2
- Features:-
- Voltage - Supply:2V ~ 5.5V
- Current - Quiescent (Max):20 µA
- Current - Output High, Low:12mA, 12mA
- Logic Level - Low:0.5V
- Logic Level - High:1.5V
- Max Propagation Delay @ V, Max CL:7.5ns @ 5V, 50pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
