74LVC06APW-Q100J
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC INVERTER OD 6CH 6-INP 14TSSOP
- CategoryLogic - Gates and Inverters
- Datasheet 74LVC06APW-Q100J Datasheet
-
ECAD Model
- Share
In Stock: 5,500
Can ship immediately
Pricing:
- 1$0.07
- 2,500$0.07
Quote It
Technical Details
- Series:74LVC
- Package:Bulk
- Part Status:Active
- Logic Type:Inverter
- Number of Circuits:6
- Number of Inputs:6
- Features:Open Drain
- Voltage - Supply:1.2V ~ 5.5V
- Current - Quiescent (Max):10 µA
- Current - Output High, Low:-, 32mA
- Logic Level - Low:0.12V ~ 0.8V
- Logic Level - High:1.08V ~ 2V
- Max Propagation Delay @ V, Max CL:2.5ns @ 5V, 50pF
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-TSSOP
- Package / Case:14-TSSOP (0.173", 4.40mm Width)
