NLV14082BDR2G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE AND 2CH 4-INP 14SOIC
- CategoryLogic - Gates and Inverters
- Datasheet NLV14082BDR2G Datasheet
-
ECAD Model
- Share
In Stock: 12,499
Can ship immediately
Pricing:
- 1$0.2
- 2,500$0.2
Quote It
Technical Details
- Series:4000B
- Package:Bulk
- Part Status:Active
- Logic Type:AND Gate
- Number of Circuits:2
- Number of Inputs:4
- Features:-
- Voltage - Supply:3V ~ 18V
- Current - Quiescent (Max):1 µA
- Current - Output High, Low:8.8mA, 8.8mA
- Logic Level - Low:1.5V ~ 4V
- Logic Level - High:3.5V ~ 11V
- Max Propagation Delay @ V, Max CL:100ns @ 15V, 50pF
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
