74LCX06MX
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionINVERTER, LVC/LCX/Z SERIES, 6-FU
- CategoryLogic - Gates and Inverters
- Datasheet 74LCX06MX Datasheet
-
ECAD Model
- Share
In Stock: 2,614
Can ship immediately
Pricing:
- 1$0.21
- 2,500$0.06769
- 5,000$0.06333
- 12,500$0.05896
- 25,000$0.0559
Quote It
Technical Details
- Series:74LCX
- Package:Bulk
- Part Status:Active
- Logic Type:Inverter
- Number of Circuits:6
- Number of Inputs:6
- Features:Open Drain
- Voltage - Supply:2V ~ 3.6V
- Current - Quiescent (Max):10 µA
- Current - Output High, Low:-, 24mA
- Logic Level - Low:0.7V ~ 0.8V
- Logic Level - High:1.7V ~ 2V
- Max Propagation Delay @ V, Max CL:3.7ns @ 3.3V, 50pF
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
