SN74S10DG4
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC GATE NAND 3CH 3-INP 14SOIC
- CategoryLogic - Gates and Inverters
-
ECAD Model
- Share
In Stock: 168
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:74S
- Package:Tube
- Part Status:Obsolete
- Logic Type:NAND Gate
- Number of Circuits:3
- Number of Inputs:3
- Features:-
- Voltage - Supply:4.75V ~ 5.25V
- Current - Quiescent (Max):-
- Current - Output High, Low:1mA, 20mA
- Logic Level - Low:0.8V
- Logic Level - High:2V
- Max Propagation Delay @ V, Max CL:5ns @ 5V, 50pF
- Operating Temperature:0°C ~ 70°C
- Mounting Type:Surface Mount
- Supplier Device Package:14-SOIC
- Package / Case:14-SOIC (0.154", 3.90mm Width)
